Enershare Power-CORE 1.0 / Enershare Energy-CORE 1.0 , European Spot Products, present you with a high voltage lithium battery energy storage solution. Our product features high-voltage stack lithium batteries, offering a single-tower capacity ranging from 4.8kWh to 25.6kWh. With the possibility of maximum expansion up to 153.6kWh, it is perfectly suitable for home energy storage and small commercial scenarios.
Enershare Power-CORE 1.0 / Enershare Energy-CORE 1.0 High Voltage Lithium Ion Battery Storage System
Product Overview
Enershare Power-CORE 1.0 / Enershare Energy-CORE 1.0 High Voltage lithium ion battery storage is a cutting-edge energy storage system (ESS) designed for European homes, commercial, and industrial applications.
This stackable battery system supports up to 6 towers in parallel with capacities from 4.8 kWh to 153.6 kWh. Each battery pack weighs ≤36.5kg, enabling one person stack installation with ease.
Our high voltage lithium ion battery packs are designed for efficiency, reliability, and safety. Ideal for solar or industrial applications, the system supports flexible stackable installation and modular expansion.
Enershare Power-CORE 1.0 / Enershare Energy-CORE 1.0 high-voltage battery system proves its excellence in small commercial and industrial storage applications. In this award-winning installation, the customer deployed 25.6kWh × 12 towers, reaching over 300kWh total capacity to secure reliable energy supply for daily operations. With professional system design, strong safety standards, and outstanding efficiency, the project delivers both sustainability and energy independence. This case sets a benchmark for small C&I storage, confirming Enershare Power-CORE 1.0 / Enershare Energy-CORE 1.0 as a trusted high-voltage battery solution for the European market.
model
Energy-CORE
Number of Stacks
3
4
5
6
7
8
Usable Energy
9.6 kWh
12.8 kWh
16 kWh
19.2 kWh
22.4 kWh
25.6 kWh
Max Output Current
30 A
Peak Output Current
50 A (5s)
Nominal Voltage
192 V
256 V
320 V
384 V
448 V
512 V
Operating Voltage Range
162~219 V
216~292 V
270~365 V
324~438 V
378~511 V
432~584 V
Scalability
Up to 6 towers in parallel (From 9,6 kWh to 153,6 kWh)
Dimensions (H*W*D) (mm)
800* 650*260 mm
975* 650*260 mm
1150* 650*260 mm
1325* 650*260 mm
1500* 650*260 mm
1675* 650*260 mm
Weight
129.5 kg
166 kg
202.5 kg
239 kg
275,5 kg
312 kg
Operation Temperature
-10~55 ºC
Protection Rating
IP65
Round-trip Efficiency
≥ 96 %
Certification & Compliance
UKCA / IEC62619 / CEC / CE / UN38.3
Applications
ON Grid / ON Grid Backup / OFF Grid
Warranty
10 Years
model
Power-CORE
Number of Stacks
2
3
4
5
Usable Energy
4.8 kWh
7.2 kWh
9.6 kWh
12 kWh
Max Output Current
25 A
Peak Output Current
50 A (5s)
Nominal Voltage
204.8 V
307.2 V
409.6 V
512 V
Operating Voltage Range
172.8~233.6 V
259.2~350.4 V
345.6~467.2 V
432~584 V
Scalability
Up to 6 towers (From 5.36 kWh to 80.4 kWh)
Dimensions (H*W*D) (mm)
625* 650* 260mm
800* 650* 260mm
975* 650* 260mm
1150* 650* 260mm
Weight
90 kg
125 kg
160 kg
195 kg
Operation Temperature
-10~55 ºC
Protection Rating
IP65
Round-trip Efficiency
≥ 95 %
Certification & Compliance
UKCA / IEC62619 / CEC / CE / UN38.3
Applications
ON Grid / ON Grid Backup / OFF Grid
Warranty
10 Years
